Inputs / Outputs
System Connection:
USB-B 3.0 / 3.1/3.2 Gen 1

Video Inputs:
(1) BNC (3G-SDI) Female

Audio Inputs:
No

Video Outputs:
1x BNC (3G-SDI) Female (Loop Output)

Format Support-
Input Video Format:
SDI
480i / 525 lines at 29.97/59.94 fps
576i / 625 lines at 25/50 fps
720p at 50/59.94/60 fps
1080i at 50/59.94/60 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

Input Audio Format:
Analog: 48 kHz / 24-Bit

Output Video Format:
USB-B
1080p at 7.5/15/25/29.97/30/50/59.94/60 fps
720p at 7.5/15/25/29.97/30/50/59.94/60 fps
1024 x 576 at 7.5/15/25/29.97/30/50/59.94/60 fps
1440 x 1080 at 7.5/15/25/29.97/30/50/59.94/60 fps
960 x 540 at 7.5/15/25/29.97/30/50/59.94/60 fps
856 x 480 at 7.5/15/25/29.97/30/50/59.94/60 fps
SVGA (800 x 600) at 7.5/15/25/29.97/30/50/59.94/60 fps
768 x 576 at 7.5/15/25/29.97/30/50/59.94/60 fps
720 x 576 at 7.5/15/25/29.97/30/50/59.94/60 fps
720 x 480 at 7.5/15/25/29.97/30/50/59.94/60 fps
VGA (640 x 480) at 7.5/15/25/29.97/30/50/59.94/60 fps
640 x 360 at 7.5/15/25/29.97/30/50/59.94/60 fps
432 x 240 at 7.5/15/25/29.97/30/50/59.94/60 fps
352 x 288 at 7.5/15/25/29.97/30/50/59.94/60 fps
QVGA (320 x 240) at 7.5/15/25/29.97/30/50/59.94/60 fps
176 x 144 at 7.5/15/25/29.97/30/50/59.94/60 fps

Output Audio Format:
Analog: 48 kHz / 16-Bit

Embedded Audio:
SDI: 2-Channel

Standards-
Video Standard Compliance:
SMPTE 259M/292M/424M

HDCP Support:
No

Hardware-
Tally Light:
Yes

OS Compatibility:
Windows 11
macOS 12.3
Linux 20

Power I/O:
(1) USB-B Input

Environmental-
Operating Temperature:
32 to 104°F / 0 to 40°C

Storage Temperature:
-40 to 140°F / -40 to 60°C

Operating Humidity:
10 to 90%


General-
Certifications:
FCC Part 15 Class A, ICES, CE, FCC, BSMI CNS 13438 Class A, VCCI Class A

Dimensions:
3.3 x 2.4 x 1" / 83.82 x 60.96 x 25.4 mm

Weight:
0.3 lb / 0.14 kg
